8 Port UPoE Rack Managed Switch 900W Budget 220V Input 2.5G Fiber Gigabit Ethernet

Name: 8 Port UPoE Rack Managed Switch 900W Budget 220V Input 25G Fiber Gigabit Ethernet
Brand: Olycom
Price: 1 USD

8 Port UPoE Rack Managed Switch 900W Budget 220V Input 2.5G Fiber Gigabit Ethernet

Categories	Industrial Managed POE Switch
Brand Name:	Olycom
Model Number:	IM-FP21008GW-U
Certification:	CE RoHS FCC ISO9001
Place of Origin:	Shenzhen, China
MOQ:	1pc
Price:	negotiable
Payment Terms:	T/T, PayPal
Supply Ability:	1500pcs/month
Delivery Time:	4~7 working days
Packaging Details:	2 pieces in a box, 10Kg G.W.
Product name:	Industrial Rack Managed Fiber Switch
Fiber rate:	100M/1000M/2500M
Ethernet rate:	100/1000Mbps
PoE budget:	720W
PoE protocol:	PoE af/at/bt
AC input:	AC100V~240V

Contact Now

Add to Cart

Company Info.

Shenzhen Olycom Technology Co., Ltd.

Verified Supplier

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

PoE++ 802.3bt (90W) 8 Port Rack Managed Network Switch

This is Gigabit Managed 10-port,L2 Gigabit Ethernet 90W PoE Ring Switch.

IEEE802.3af/at/bt compliant up to 90W PoE power on 8 copper ports for total power of 720W to provide power for the most demanding PoE applications for PTz domes, LED lighting and wireless products
Compliant to G.8032 ERPS V1/V2 Ring protocol
uniquely designed for outdoor enclosure applications with a ribbed temperature disbursement chassis ,6kv surge protection and user programmable port thermal protection of over temperature shut down to prevent damage from excessive heat

Features

8x 10/100/1000Base-T RJ-45 and 2x 100/1000/2500Base-T SFP Fiber
2 Copper/MSA Fiber Combo ports
Cable diagnostic, Measuring cable normal or broken point distance
Supports Green Ethernet IEEE802.3az EEE (Energy Efficient Ethernet) management to optimize the power Consumption
STP, RSTP, MSTP, ITU-T G.8032 Ethernet Ring Protection Switching (ERPS) for redundant cabling
DHCP Server/Client/Relay/Snooping/Snooping option 82/Relay option 82
QoS, Traffic classification QoS, CoS, bandwidth control for Ingress and Egress, Storm Control
IEEE802.1q VLAN, MAC based VLAN, IP subnet based VLAN, Protocol based VLAN, VLAN translation, GVRP, MVR
Dynamic IEEE 802.3ad LACP Link Aggregation, Static Link Aggregation
IGMP snooping V1/V2/V3, IGMP Filtering/ Throttling, IGMP query, IGMP proxy reporting, MLD snooping V1/V2
Security : Port based and MAC based IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, SSL/SSH v2
Software upgrade via TFTP and HTTP, redundant firmware to avoid in case of upgrade failure
Supports IEEE1588 PTP V2 for precise time synchronization to operate in Ordinary-Boundary, Peer to Peer Transparent Clock, End to End
Transparent Clock, Master, Slave mode by each port
RMON, MIB II, Port mirroring, Event syslog, DNS, NTP, IEEE802.1ab LLDP
Supports IPv6 Telnet server /ICMP v6
CLI, Web based management, SNMP v1/v2c/v3, Telnet server for management

Specification

Product Name	10/100/1000Mbps Managed Industrial POE Fiber Switch(2F+10TP)
Port	2 x 1000Mpbs SFP port, 1G/2.5G both supportive SM: 1310nm/1550nm,20Km; 1490nm/1550nm, 40~120Km; MM: 1310nm, 2Km; 850nm, 500 meters 8x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
Standard	IEEE 802.3, IEEE802.3U, IEEE802.3ab, IEEE802.3z, IEEE802.1d STP, IEEE802.1w RSTP, IEEE802.1s MSTP, ITU-T G.8023 EPR/Y.1344, IEEE802.1Q, IEEE802.1X, IEEE802.3ad, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.1ad, IEEE802.1p, IEEE802.1ab, IEEE802.3az
VLAND ID	4096
Jumbo Frame	9.6KB
MAC Address	8K
Switching features	Transmission mode: Storage and forward System bandwidth: 58Gbps (non-traffic jam)
Network media	10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m) 100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m) SFP port, transmission distance: 20Km, 40Km, 60Km, 80Km, 100Km
LEDs	Power, network, fiber, POE, alarm
Power supply	POE power supply input voltage: 48V (max 57V) Single PoE power supply output power: 15.4W/30W/60W/90W(port 1~8)

Application

Dimension
