| Brand Name: | Fongko |
| Model Number: | FKEQU-212 |
| Place of Origin: | China |
| MOQ: | 1 Pieces |
| Price: | Negotiatable |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Product name: | Visual Fault Locator |
| Application: | Telecom Network |
| Fiber Optic Adapter: | Universal Connector |
| Storage Temperature: | -20~70℃ |
| Wavelength: | 1310nm / 1550nm |
| Output Wavelength:: | 650nm |
| Company Info. |
| Shenzhen Fongko Communication Equipment Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
FONGKO Chargeable 5mw 15mw 20mw 30mw Lithium battery Fiber Optic Cable Red Lase Visual Fault Locator VFL
Introduction:
650nm visual fault locator has the function of fiber identification
and faults locator of SM or MM fiber, it is a helpful
assistant to dead zone of OTDR, it is also a basic maintenance tool
for fiber network, LAN, ATM fiber system and telecom network
system.
Features:
--Support CW and 2Hz modulation work mode
--Solid: use special laser end design to avoid damage when dropping
on the floor.
--Long working hours: use effective laser drive circuit to ensure
1mW/650nm locator can work more than 10 hours continuously.
--Stable power output: use special laser driver circuit, which can
ensure stable power output in the low battery.
--2.5mm universal adapter: use 2.5mm universal adapter, can match
SC/LC adapters.
Wavelength | 650nm±10nm |
Light source | FP-LD laser |
Output power | Dry battery:5mw,15mw Lithium battery:5mw,15mw,20mW,30mW (optional) |
Connector | 2.5mm universal adapter |
Working mode | CW or 2Hz modulation |
Operating temperature | -20~+60 °C |
Storage temperature | -25~+70 °C |
Power | 2pcs AA battery/Lithium battery |
Weight | 83g |
|
